石笼网由高抗腐蚀、高强度、具有延展性的低碳钢丝或者包覆PVC的以上钢丝使用机械编织而成，使用该网制作而成的箱型结构就是石笼。根据ASTM和EN标准，所使用的低碳钢丝直径根据工程设计要求而不同。一般介于2.0-4.0mm之间，石笼网钢丝的抗拉强度不少于38kg/㎡，金属镀层重量一般高于245g/㎡，石笼网片的边缘线直径一般要大于网线直径。其双线绞合部分的长度不得小于50mm以保证绞合部分钢丝的金属镀层和PVC镀层不受破坏。
The gabion mesh is made of low-carbon steel wire with high corrosion resistance, high strength, and ductility, or steel wire coated with PVC, which is mechanically woven. The box shaped structure made of this mesh is called a gabion. According to ASTM and EN standards, the diameter of low-carbon steel wire used varies according to engineering design requirements. Generally between 2.0-4.0mm, the tensile strength of the gabion mesh steel wire is not less than 38kg/㎡, the weight of the metal coating is generally higher than 245g/㎡, and the diameter of the edge line of the gabion mesh is generally larger than that of the mesh wire. The length of the twisted part of the double wire shall not be less than 50mm to ensure that the metal coating and PVC coating of the twisted part steel wire are not damaged.
